Adhesive Tapes
AGF-100FR ORANGE
- Adhesive Tapes
- Fluororesin/Glass cloth based material
- UL Standard
- RoHS Directive
Overview
Adhesive tape with an orange-colored fluoroplastic (made with PTFE)-impregnated glass cloth as the base material and applied silicone adhesive on one side.
In addition to various excellent properties of fluoroplastic, its orange-colored surface makes this product an optimum choice for distinguishing high-voltage wiring of electric vehicles (EV).
Main applications
• Distinguish high-voltage wiring of electric vehicles (EV).
• Electrical insulation covering for cables.
Operating temperature limit
-60°C to +200°C
Structure
Characteristics
• The orange-colored surface provides excellent noticeability.
• Excellent heat resistance, sliding property, chemical resistivity, electric insulation, and flame retardance.
Typical dimensions
| Total thickness (mm) | Width (mm) | Length (m) |
|---|---|---|
| Standard | ||
| 0.11 | 19 | 30 |
*Please consult us separately for the dimensions other than above.
Typical properties
| Product code | Total thickness (mm) | Adhesion 90° peel test (N/25mm) | Tensile strength (N/25mm) | Breakdown voltage (kV) | Maximum service temperature (°C) |
|---|---|---|---|---|---|
| AGF-100FR ORANGE | 0.11 | 9.3 | 285 | 6.1 | 200 |
*Values shown in this table represent measurements and do not constitute guaranteed values.
