C-Porous™ PTFE porous products
PTFE porous film SEF-5008-03
- C-Porous™ PTFE porous products
- PTFE Porous Film
- ROHS Directive
overview
This product is made by porous PTFE and forming it into a film. It has significantly superior water pressure resistance compared to conventional products such as the "SEF-010 series" and other specifications. It can also be supplied as die-cut products or with double-sided tape attached.
Applications
• Filter-
• Air vent
• Waterproof and soundproof (mobile devices)
• Degassing
Enlarged photo
(1000 times)
structure
Features
●It offers both air permeability and water repellent performance.
● It has extremely excellent water pressure resistance.
●It possesses Weatherability, chemical resistance, lowest friction, flexibility, and heat insulating characteristics.
●The micropores provide air permeability and moisture permeability while also offering waterproof and water-repellent properties.
● We can also perform sealing and die-cutting in various shapes.
● Comply with Food Sanitation Act Amendment (enforced from June 1, 2020) in Japan as food apparatus, containers and packaging.
water resistance
It has significantly superior water resistance compared to conventional products.
Dimensions
| Product code | Thickness (mm) | Width (mm) | Length (m) |
|---|---|---|---|
| SEF-5008-03 | 0.095 | 300～600 | 10~70 |
*For sizes other than those listed above, please contact us separately.
Characteristics table
| Product code | Air permeability (sec) | Water resistance (kPa) |
|---|---|---|
| SEF-5008-03 | 35 | 1300 |
*The values in the table above are measured values and not standard values.
*Air permeability is the value measured using a Gurley-type air permeability tester conforming to JISP8117.
