Adhesive Tapes
ASF-110B
- Adhesive Tapes
- Fluororesin/Film based material
- RoHS Directive
Overview
This tape consists of acrylic adhesive applied to a base material made of fluoroplastic (PTFE) film.
This product can be used in applications where silicone is not suitable.
Main applications
•Slippage enhancement, masking and insulation covering in a place where silicone is not suitable
Maximum operating temperature
+80°C
Structure
Characteristics
• This is silicone-free* fluoroplastics tape using acrylic adhesives.
• The surface of the tape has excellent insulation, non-stick property, slipping characteristics, clean release characteristics, chemical resistance and water repellency.
*Silicone material is not intentionally used.
Typical dimensions
| Total thickness (mm) | Width (mm) | Maximum width (mm) | Length (m) |
|---|---|---|---|
| Normal stock | |||
| 0.08 | – | 350 | 10 |
| 0.13 | 25 | 350 | 10 |
*Tapes can be slit to widths not shown above up to the maximum width.
*Please consult us separately for the dimensions other than above.
Typical properties
| Product code | Total thickness (mm) | Tensile strength (N/25mm) | Elongation (%) | Adhesion 180° peel test (N/25mm) | Breakdown voltage kV | Maximum operating temperature (°C) |
|---|---|---|---|---|---|---|
| ASF-110B | 0.08 | 70 | 180 | 9 | 10 | 80 |
| 0.13 | 160 | 180 | 9 | 15 | 80 |
*Values shown in this table represent measurements and do not constitute guaranteed values.
